Part No. 716001 ES YM2 16

GTIN 4013364010406, Customs tariff No. (EU): 85446010, Gross weight: 1.00 m/Stk, PU: 1.00 pc(s)

Images

Additional information

Technical data

Cable cross-section	16 mm²
Minimum order quantity ^*)	1 m
^*) Length of earthing cable to be specified when ordering (in whole metres).

Version	Single-pole
Cable cross-section	16 mm²
Minimum order quantity ^*)	1 m
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
^*) Length of earthing cable to be specified when ordering (in whole metres).

Product 716001 was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. 725001 ES YM2 25

GTIN 4013364011793, Customs tariff No. (EU): 85446010, Gross weight: 207.00 g/m, PU: 1.00 m

Images

Additional information

Technical data

Cable cross-section	25 mm²
Minimum order quantity ^*)	1 m
^*) Length of earthing cable to be specified when ordering (in whole metres).

Version	Single-pole
Cable cross-section	25 mm²
Minimum order quantity ^*)	1 m
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
^*) Length of earthing cable to be specified when ordering (in whole metres).

Product 725001 was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. 735001 ES YM2 35

GTIN 4013364011847, Customs tariff No. (EU): 85446010, Gross weight: 366.00 g/m, PU: 1.00 m

Images

Additional information

Technical data

Cable cross-section	35 mm²
Minimum order quantity ^*)	1 m
^*) Length of earthing cable to be specified when ordering (in whole metres).

Version	Single-pole
Cable cross-section	35 mm²
Minimum order quantity ^*)	1 m
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
^*) Length of earthing cable to be specified when ordering (in whole metres).

Product 735001 was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. 750001 ES YM2 50

GTIN 4013364011809, Customs tariff No. (EU): 85446010, Gross weight: 535.00 g/m, PU: 1.00 m

Images

Additional information

Technical data

Cable cross-section	50 mm²
Minimum order quantity ^*)	1 m
^*) Length of earthing cable to be specified when ordering (in whole metres).

Version	Single-pole
Cable cross-section	50 mm²
Minimum order quantity ^*)	1 m
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
^*) Length of earthing cable to be specified when ordering (in whole metres).

Product 750001 was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. 770001 ES YM2 70

GTIN 4013364011762, Customs tariff No. (EU): 85446010, Gross weight: 753.00 g/m, PU: 1.00 m

Images

Additional information

Technical data

Cable cross-section	70 mm²
Minimum order quantity ^*)	1 m
^*) Length of earthing cable to be specified when ordering (in whole metres).

Version	Single-pole
Cable cross-section	70 mm²
Minimum order quantity ^*)	1 m
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
^*) Length of earthing cable to be specified when ordering (in whole metres).

Product 770001 was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. 795001 ES YM2 95

GTIN 4013364011816, Customs tariff No. (EU): 85446010, Gross weight: 1.00 kg/m, PU: 1.00 m

Images

Additional information

Technical data

Cable cross-section	95 mm²
Minimum order quantity ^*)	1 m
^*) Length of earthing cable to be specified when ordering (in whole metres).

Version	Single-pole
Cable cross-section	95 mm²
Minimum order quantity ^*)	1 m
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
^*) Length of earthing cable to be specified when ordering (in whole metres).

Product 795001 was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. 712001 ES YM2 120

GTIN 4013364011823, Customs tariff No. (EU): 85446010, Gross weight: 1230.00 g/m, PU: 1.00 m

Images

Additional information

Technical data

Cable cross-section	120 mm²
Minimum order quantity ^*)	1 m
^*) Length of earthing cable to be specified when ordering (in whole metres).

Version	Single-pole
Cable cross-section	120 mm²
Minimum order quantity ^*)	1 m
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
^*) Length of earthing cable to be specified when ordering (in whole metres).

Product 712001 was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. 715001 ES YM2 150

GTIN 4013364011830, Customs tariff No. (EU): 85446010, Gross weight: 1520.00 g/m, PU: 1.00 m

Images

Additional information

Technical data

Cable cross-section	150 mm²
Minimum order quantity ^*)	1 m
^*) Length of earthing cable to be specified when ordering (in whole metres).

Version	Single-pole
Cable cross-section	150 mm²
Minimum order quantity ^*)	1 m
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
^*) Length of earthing cable to be specified when ordering (in whole metres).

Product 715001 was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VGHVBP5 EKV1+0 35 VGHVBP5

GTIN 4013364360389, Customs tariff No. (EU): 85359000, Gross weight: 2.17 kg, PU: 1.00 pc(s)

Images

Additional information

Technical data

Cable cross-section	35 mm²
Max. short-circuit current I_k0.5 s	6.5 kA
Max. short-circuit current I_k1 s	4.6 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Single-pole
Cable cross-section (phase side)	35 mm²
Cable cross-section (earth side)	35 mm²
Length of single-pole cable	5000 mm
Cable cross-section	35 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	6.5 kA
Max. short-circuit current I_k1 s	4.6 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	Al
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VGHVBP5 was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VKVBG8W EKV1+0 50 VKVBG8W

GTIN 4013364360136, Customs tariff No. (EU): 85359000, Gross weight: 2.55 kg, PU: 1.00 pc(s)

Images

Additional information

Technical data

Cable cross-section	50 mm²
Max. short-circuit current I_k0.5 s	9.3 kA
Max. short-circuit current I_k1 s	6.6 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Single-pole
Cable cross-section (phase side)	50 mm²
Cable cross-section (earth side)	50 mm²
Length of single-pole cable	5000 mm
Cable cross-section	50 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	9.3 kA
Max. short-circuit current I_k1 s	6.6 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	Al
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VKVBG8W was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. V4YPRGE EKV1+0 16 V4YPRGE

GTIN 4013364165243, Customs tariff No. (EU): 85359000, Gross weight: 1.26 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	16 mm²
Max. short-circuit current I_k0.5 s	4.5 kA
Max. short-circuit current I_k1 s	3.2 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Single-pole
Cable cross-section (phase side)	16 mm²
Cable cross-section (earth side)	16 mm²
Length of single-pole cable	5000 mm
Cable cross-section	16 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	4.5 kA
Max. short-circuit current I_k1 s	3.2 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product V4YPRGE was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VSY71K4 EKV1+0 25 VSY71K4

GTIN 4013364163287, Customs tariff No. (EU): 85359000, Gross weight: 1.15 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	25 mm²
Max. short-circuit current I_k0.5 s	7.0 kA
Max. short-circuit current I_k1 s	4.9 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Single-pole
Cable cross-section (phase side)	25 mm²
Cable cross-section (earth side)	25 mm²
Length of single-pole cable	5000 mm
Cable cross-section	25 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	7.0 kA
Max. short-circuit current I_k1 s	4.9 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VSY71K4 was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. V9JF26K EKV1+0 35 V9JF26K

GTIN 4013364163294, Customs tariff No. (EU): 85359000, Gross weight: 2.26 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	35 mm²
Max. short-circuit current I_k0.5 s	10.0 kA
Max. short-circuit current I_k1 s	6.9 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Single-pole
Cable cross-section (phase side)	35 mm²
Cable cross-section (earth side)	35 mm²
Length of single-pole cable	5000 mm
Cable cross-section	35 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	10.0 kA
Max. short-circuit current I_k1 s	6.9 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product V9JF26K was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VRJG23Y EKV1+0 50 VRJG23Y

GTIN 4013364163300, Customs tariff No. (EU): 85359000, Gross weight: 3.10 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	50 mm²
Max. short-circuit current I_k0.5 s	14.0 kA
Max. short-circuit current I_k1 s	9.9 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Single-pole
Cable cross-section (phase side)	50 mm²
Cable cross-section (earth side)	50 mm²
Length of single-pole cable	5000 mm
Cable cross-section	50 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	14.0 kA
Max. short-circuit current I_k1 s	9.9 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VRJG23Y was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VPZBBSL EKV1+0 70 VPZBBSL

GTIN 4013364163317, Customs tariff No. (EU): 85359000, Gross weight: 4.50 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	70 mm²
Max. short-circuit current I_k0.5 s	19.5 kA
Max. short-circuit current I_k1 s	13.8 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Single-pole
Cable cross-section (phase side)	70 mm²
Cable cross-section (earth side)	70 mm²
Length of single-pole cable	5000 mm
Cable cross-section	70 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	19.5 kA
Max. short-circuit current I_k1 s	13.8 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VPZBBSL was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VZC3FST EKV1+0 95 VZC3FST

GTIN 4013364163324, Customs tariff No. (EU): 85359000, Gross weight: 5.64 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	95 mm²
Max. short-circuit current I_k0.5 s	26.5 kA
Max. short-circuit current I_k1 s	18.7 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Single-pole
Cable cross-section (phase side)	95 mm²
Cable cross-section (earth side)	95 mm²
Length of single-pole cable	5000 mm
Cable cross-section	95 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	26.5 kA
Max. short-circuit current I_k1 s	18.7 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VZC3FST was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. V797FE6 EKV1+0 120 V797FE6

GTIN 4013364163188, Customs tariff No. (EU): 85359000, Gross weight: 7.03 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	120 mm²
Max. short-circuit current I_k0.5 s	33.5 kA
Max. short-circuit current I_k1 s	23.7 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Single-pole
Cable cross-section (phase side)	120 mm²
Cable cross-section (earth side)	120 mm²
Length of single-pole cable	5000 mm
Cable cross-section	120 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	33.5 kA
Max. short-circuit current I_k1 s	23.7 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product V797FE6 was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VB53TC9 EKV1+0 150 VB53TC9

GTIN 4013364163270, Customs tariff No. (EU): 85359000, Gross weight: 8.72 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	150 mm²
Max. short-circuit current I_k0.5 s	42.0 kA
Max. short-circuit current I_k1 s	29.6 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Single-pole
Cable cross-section (phase side)	150 mm²
Cable cross-section (earth side)	150 mm²
Length of single-pole cable	5000 mm
Cable cross-section	150 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	42.0 kA
Max. short-circuit current I_k1 s	29.6 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VB53TC9 was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. V7265NS EKV2+0 16 G V7265NS

GTIN 4013364163355, Customs tariff No. (EU): 85359000, Gross weight: 1.16 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	16 mm²
Max. short-circuit current I_k0.5 s	4.5 kA
Max. short-circuit current I_k1 s	3.2 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Two-pole
Cable cross-section (phase side)	16 mm²
Cable cross-section (earth side)	16 mm²
Length of phase cable A	600 mm
Length of phase cable C	600 mm
Length of earthing cable	1800 mm
Cable cross-section	16 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	4.5 kA
Max. short-circuit current I_k1 s	3.2 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product V7265NS was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VZL6TGH EKV2+0 25 G VZL6TGH

GTIN 4013364163362, Customs tariff No. (EU): 85359000, Gross weight: 1.47 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	25 mm²
Max. short-circuit current I_k0.5 s	7.0 kA
Max. short-circuit current I_k1 s	4.9 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Two-pole
Cable cross-section (phase side)	25 mm²
Cable cross-section (earth side)	25 mm²
Length of phase cable A	600 mm
Length of phase cable C	600 mm
Length of earthing cable	1800 mm
Cable cross-section	25 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	7.0 kA
Max. short-circuit current I_k1 s	4.9 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VZL6TGH was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VPHPZV2 EKV2+0 35 G VPHPZV2

GTIN 4013364163379, Customs tariff No. (EU): 85359000, Gross weight: 1.67 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	35 mm²
Max. short-circuit current I_k0.5 s	10.0 kA
Max. short-circuit current I_k1 s	6.9 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Two-pole
Cable cross-section (phase side)	35 mm²
Cable cross-section (earth side)	35 mm²
Length of phase cable A	600 mm
Length of phase cable C	600 mm
Length of earthing cable	1800 mm
Cable cross-section	35 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	10.0 kA
Max. short-circuit current I_k1 s	6.9 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VPHPZV2 was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VJ13VWW EKV2+0 50 G VJ13VWW

GTIN 4013364162136, Customs tariff No. (EU): 85359000, Gross weight: 2.43 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	50 mm²
Max. short-circuit current I_k0.5 s	14.0 kA
Max. short-circuit current I_k1 s	9.9 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Two-pole
Cable cross-section (phase side)	50 mm²
Cable cross-section (earth side)	50 mm²
Length of phase cable A	600 mm
Length of phase cable C	600 mm
Length of earthing cable	1800 mm
Cable cross-section	50 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	14.0 kA
Max. short-circuit current I_k1 s	9.9 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VJ13VWW was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VTJKEZU EKV2+0 70 G VTJKEZU

GTIN 4013364165250, Customs tariff No. (EU): 85359000, Gross weight: 3.46 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	70 mm²
Max. short-circuit current I_k0.5 s	19.5 kA
Max. short-circuit current I_k1 s	13.8 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Two-pole
Cable cross-section (phase side)	70 mm²
Cable cross-section (earth side)	70 mm²
Length of phase cable A	600 mm
Length of phase cable C	600 mm
Length of earthing cable	1800 mm
Cable cross-section	70 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	19.5 kA
Max. short-circuit current I_k1 s	13.8 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VTJKEZU was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VAM7M6H EKV2+0 95 G VAM7M6H

GTIN 4013364165267, Customs tariff No. (EU): 85359000, Gross weight: 4.63 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	95 mm²
Max. short-circuit current I_k0.5 s	26.5 kA
Max. short-circuit current I_k1 s	18.7 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Two-pole
Cable cross-section (phase side)	95 mm²
Cable cross-section (earth side)	95 mm²
Length of phase cable A	600 mm
Length of phase cable C	600 mm
Length of earthing cable	1800 mm
Cable cross-section	95 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	26.5 kA
Max. short-circuit current I_k1 s	18.7 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)s
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VAM7M6H was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VFV1Z7K EKV2+0 120 G VFV1Z7K

GTIN 4013364163331, Customs tariff No. (EU): 85359000, Gross weight: 5.54 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	120 mm²
Max. short-circuit current I_k0.5 s	33.5 kA
Max. short-circuit current I_k1 s	23.7 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Two-pole
Cable cross-section (phase side)	120 mm²
Cable cross-section (earth side)	120 mm²
Length of phase cable A	600 mm
Length of phase cable C	600 mm
Length of earthing cable	1800 mm
Cable cross-section	120 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	33.5 kA
Max. short-circuit current I_k1 s	23.7 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VFV1Z7K was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VLL6JWS EKV2+0 150 G VLL6JWS

GTIN 4013364163348, Customs tariff No. (EU): 85359000, Gross weight: 6.46 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	150 mm²
Max. short-circuit current I_k0.5 s	42.0 kA
Max. short-circuit current I_k1 s	29.6 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Two-pole
Cable cross-section (phase side)	150 mm²
Cable cross-section (earth side)	150 mm²
Length of phase cable A	600 mm
Length of phase cable C	600 mm
Length of earthing cable	1800 mm
Cable cross-section	150 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	42.0 kA
Max. short-circuit current I_k1 s	29.6 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VLL6JWS was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VE5MT89 EKV3+0 16 G VE5MT89

GTIN 4013364163522, Customs tariff No. (EU): 85359000, Gross weight: 1.36 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	16 mm²
Max. short-circuit current I_k0.5 s	4.5 kA
Max. short-circuit current I_k1 s	3.2 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Three-pole
Cable cross-section (phase side)	16 mm²
Cable cross-section (earth side)	16 mm²
Length of phase cable A	600 mm
Length of phase cable B	600 mm
Length of phase cable C	600 mm
Length of earthing cable	1800 mm
Cable cross-section	16 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	4.5 kA
Max. short-circuit current I_k1 s	3.2 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VE5MT89 was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VNC1S9W EKV3+0 25 G VNC1S9W

GTIN 4013364163539, Customs tariff No. (EU): 85359000, Gross weight: 1.73 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	25 mm²
Max. short-circuit current I_k0.5 s	7.0 kA
Max. short-circuit current I_k1 s	4.9 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Three-pole
Cable cross-section (phase side)	25 mm²
Cable cross-section (earth side)	25 mm²
Length of phase cable A	600 mm
Length of phase cable B	600 mm
Length of phase cable C	600 mm
Length of earthing cable	1800 mm
Cable cross-section	25 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	7.0 kA
Max. short-circuit current I_k1 s	4.9 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VNC1S9W was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. V18JQHQ EKV3+0 35 G V18JQHQ

GTIN 4013364163546, Customs tariff No. (EU): 85359000, Gross weight: 2.08 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	35 mm²
Max. short-circuit current I_k0.5 s	10.0 kA
Max. short-circuit current I_k1 s	6.9 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Three-pole
Cable cross-section (phase side)	35 mm²
Cable cross-section (earth side)	35 mm²
Length of phase cable A	600 mm
Length of phase cable B	600 mm
Length of phase cable C	600 mm
Length of earthing cable	1800 mm
Cable cross-section	35 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	10.0 kA
Max. short-circuit current I_k1 s	6.9 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product V18JQHQ was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VJ7VGZD EKV3+0 50 G VJ7VGZD

GTIN 4013364163553, Customs tariff No. (EU): 85359000, Gross weight: 2.83 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	50 mm²
Max. short-circuit current I_k0.5 s	14.0 kA
Max. short-circuit current I_k1 s	9.9 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Three-pole
Cable cross-section (phase side)	50 mm²
Cable cross-section (earth side)	50 mm²
Length of phase cable A	600 mm
Length of phase cable B	600 mm
Length of phase cable C	600 mm
Length of earthing cable	1800 mm
Cable cross-section	50 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	14.0 kA
Max. short-circuit current I_k1 s	9.9 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VJ7VGZD was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VH95BZZ EKV3+0 70 G VH95BZZ

GTIN 4013364165274, Customs tariff No. (EU): 85359000, Gross weight: 3.70 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	70 mm²
Max. short-circuit current I_k0.5 s	19.5 kA
Max. short-circuit current I_k1 s	13.8 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Three-pole
Cable cross-section (phase side)	70 mm²
Cable cross-section (earth side)	70 mm²
Length of phase cable A	600 mm
Length of phase cable B	600 mm
Length of phase cable C	600 mm
Length of earthing cable	1800 mm
Cable cross-section	70 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	19.5 kA
Max. short-circuit current I_k1 s	13.8 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VH95BZZ was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VM2J7S3 EKV3+0 95 G VM2J7S3

GTIN 4013364165281, Customs tariff No. (EU): 85359000, Gross weight: 5.43 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	95 mm²
Max. short-circuit current I_k0.5 s	26.5 kA
Max. short-circuit current I_k1 s	18.7 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Three-pole
Cable cross-section (phase side)	95 mm²
Cable cross-section (earth side)	95 mm²
Length of phase cable A	600 mm
Length of phase cable B	600 mm
Length of phase cable C	600 mm
Length of earthing cable	1800 mm
Cable cross-section	95 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	26.5 kA
Max. short-circuit current I_k1 s	18.7 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VM2J7S3 was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. V8D4AQ2 EKV3+0 120 G V8D4AQ2

GTIN 4013364163485, Customs tariff No. (EU): 85359000, Gross weight: 6.42 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	120 mm²
Max. short-circuit current I_k0.5 s	33.5 kA
Max. short-circuit current I_k1 s	23.7 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Three-pole
Cable cross-section (phase side)	120 mm²
Cable cross-section (earth side)	120 mm²
Length of phase cable A	600 mm
Length of phase cable B	600 mm
Length of phase cable C	600 mm
Length of earthing cable	1800 mm
Cable cross-section	120 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	33.5 kA
Max. short-circuit current I_k1 s	23.7 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product V8D4AQ2 was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VG3V6T2 EKV3+0 150 G VG3V6T2

GTIN 4013364165298, Customs tariff No. (EU): 85359000, Gross weight: 7.70 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	150 mm²
Max. short-circuit current I_k0.5 s	42.0 kA
Max. short-circuit current I_k1 s	29.6 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Three-pole
Cable cross-section (phase side)	150 mm²
Cable cross-section (earth side)	150 mm²
Length of phase cable A	600 mm
Length of phase cable B	600 mm
Length of phase cable C	600 mm
Length of earthing cable	1800 mm
Cable cross-section	150 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	42.0 kA
Max. short-circuit current I_k1 s	29.6 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VG3V6T2 was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VN35H5D EKV3+0 50 R VN35H5D

GTIN 4013364163560, Customs tariff No. (EU): 85359000, Gross weight: 2.35 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	50/25 mm²
Max. short-circuit current I_k0.5 s	14.0 kA
Max. short-circuit current I_k1 s	9.9 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Three-pole
Cable cross-section (phase side)	50 mm²
Cable cross-section (earth side)	25 mm²
Length of phase cable A	600 mm
Length of phase cable B	600 mm
Length of phase cable C	600 mm
Length of earthing cable	1800 mm
Cable cross-section	50/25 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	14.0 kA
Max. short-circuit current I_k1 s	9.9 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VN35H5D was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VTCS2XV EKV3+0 70 R VTCS2XV

GTIN 4013364163584, Customs tariff No. (EU): 85359000, Gross weight: 3.00 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	70/35 mm²
Max. short-circuit current I_k0.5 s	19.5 kA
Max. short-circuit current I_k1 s	13.8 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Three-pole
Cable cross-section (phase side)	70 mm²
Cable cross-section (earth side)	35 mm²
Length of phase cable A	600 mm
Length of phase cable B	600 mm
Length of phase cable C	600 mm
Length of earthing cable	1800 mm
Cable cross-section	70/35 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	19.5 kA
Max. short-circuit current I_k1 s	13.8 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VTCS2XV was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VLB2F3G EKV3+0 95 R VLB2F3G

GTIN 4013364163607, Customs tariff No. (EU): 85359000, Gross weight: 4.21 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	95/35 mm²
Max. short-circuit current I_k0.5 s	26.5 kA
Max. short-circuit current I_k1 s	18.7 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Three-pole
Cable cross-section (phase side)	95 mm²
Cable cross-section (earth side)	35 mm²
Length of phase cable A	600 mm
Length of phase cable B	600 mm
Length of phase cable C	600 mm
Length of earthing cable	1800 mm
Cable cross-section	95/35 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	26.5 kA
Max. short-circuit current I_k1 s	18.7 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VLB2F3G was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. V8115WA EKV3+0 120 R V8115WA

GTIN 4013364163508, Customs tariff No. (EU): 85359000, Gross weight: 4.98 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	120/50 mm²
Max. short-circuit current I_k0.5 s	33.5 kA
Max. short-circuit current I_k1 s	23.7 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Three-pole
Cable cross-section (phase side)	120 mm²
Cable cross-section (earth side)	50 mm²
Length of phase cable A	600 mm
Length of phase cable B	600 mm
Length of phase cable C	600 mm
Length of earthing cable	1800 mm
Cable cross-section	120/50 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	33.5 kA
Max. short-circuit current I_k1 s	23.7 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product V8115WA was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. V11E77B EKV3+0 150 R V11E77B

GTIN 4013364163515, Customs tariff No. (EU): 85359000, Gross weight: 5.68 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	150/50 mm²
Max. short-circuit current I_k0.5 s	42.0 kA
Max. short-circuit current I_k1 s	29.6 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Three-pole
Cable cross-section (phase side)	150 mm²
Cable cross-section (earth side)	50 mm²
Length of phase cable A	600 mm
Length of phase cable B	600 mm
Length of phase cable C	600 mm
Length of earthing cable	1800 mm
Cable cross-section	150/50 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	42.0 kA
Max. short-circuit current I_k1 s	29.6 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product V11E77B was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VGUVRRG EKV4u0 16 G VGUVRRG

GTIN 4013364164000, Customs tariff No. (EU): 85359000, Gross weight: 1.84 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	16 mm²
Max. short-circuit current I_k0.5 s	4.5 kA
Max. short-circuit current I_k1 s	3.2 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Four-pole
Cable cross-section (phase side)	16 mm²
Cable cross-section (earth side)	16 mm²
Length of phase cable A	600 mm
Length of phase cable B	600 mm
Length of phase cable C	600 mm
Length of phase cable F	600 mm
Length of earthing cable	1800 mm
Cable cross-section	16 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	4.5 kA
Max. short-circuit current I_k1 s	3.2 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VGUVRRG was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VGM214B EKV4u0 25 G VGM214B

GTIN 4013364164017, Customs tariff No. (EU): 85359000, Gross weight: 2.17 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	25 mm²
Max. short-circuit current I_k0.5 s	7.0 kA
Max. short-circuit current I_k1 s	4.9 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Four-pole
Cable cross-section (phase side)	25 mm²
Cable cross-section (earth side)	25 mm²
Length of phase cable A	600 mm
Length of phase cable B	600 mm
Length of phase cable C	600 mm
Length of phase cable F	600 mm
Length of earthing cable	1800 mm
Cable cross-section	25 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	7.0 kA
Max. short-circuit current I_k1 s	4.9 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VGM214B was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. V93UVAP EKV4u0 35 G V93UVAP

GTIN 4013364164024, Customs tariff No. (EU): 85359000, Gross weight: 2.57 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	35 mm²
Max. short-circuit current I_k0.5 s	10.0 kA
Max. short-circuit current I_k1 s	6.9 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Four-pole
Cable cross-section (phase side)	35 mm²
Cable cross-section (earth side)	35 mm²
Length of phase cable A	600 mm
Length of phase cable B	600 mm
Length of phase cable C	600 mm
Length of phase cable F	600 mm
Length of earthing cable	1800 mm
Cable cross-section	35 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	10.0 kA
Max. short-circuit current I_k1 s	6.9 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product V93UVAP was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. V3NCSHX EKV4u0 50 G V3NCSHX

GTIN 4013364164031, Customs tariff No. (EU): 85359000, Gross weight: 3.92 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	50 mm²
Max. short-circuit current I_k0.5 s	14.0 kA
Max. short-circuit current I_k1 s	9.9 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Four-pole
Cable cross-section (phase side)	50 mm²
Cable cross-section (earth side)	50 mm²
Length of phase cable A	600 mm
Length of phase cable B	600 mm
Length of phase cable C	600 mm
Length of phase cable F	600 mm
Length of earthing cable	1800 mm
Cable cross-section	50 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	14.0 kA
Max. short-circuit current I_k1 s	9.9 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product V3NCSHX was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. V7GN8WU EKV4u0 70 G V7GN8WU

GTIN 4013364162389, Customs tariff No. (EU): 85359000, Gross weight: 4.78 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	70 mm²
Max. short-circuit current I_k0.5 s	19.5 kA
Max. short-circuit current I_k1 s	13.8 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Four-pole
Cable cross-section (phase side)	70 mm²
Cable cross-section (earth side)	70 mm²
Length of phase cable A	600 mm
Length of phase cable B	600 mm
Length of phase cable C	600 mm
Length of phase cable F	600 mm
Length of earthing cable	1800 mm
Cable cross-section	70 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	19.5 kA
Max. short-circuit current I_k1 s	13.8 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product V7GN8WU was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VABRSSE EKV4u0 95 G VABRSSE

GTIN 4013364164048, Customs tariff No. (EU): 85359000, Gross weight: 7.12 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	95 mm²
Max. short-circuit current I_k0.5 s	26.5 kA
Max. short-circuit current I_k1 s	18.7 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Four-pole
Cable cross-section (phase side)	95 mm²
Cable cross-section (earth side)	95 mm²
Length of phase cable A	600 mm
Length of phase cable B	600 mm
Length of phase cable C	600 mm
Length of phase cable F	600 mm
Length of earthing cable	1800 mm
Cable cross-section	95 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	26.5 kA
Max. short-circuit current I_k1 s	18.7 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VABRSSE was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. V27E2GP EKV4u0 120 G V27E2GP

GTIN 4013364163980, Customs tariff No. (EU): 85359000, Gross weight: 8.38 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	120 mm²
Max. short-circuit current I_k0.5 s	33.5 kA
Max. short-circuit current I_k1 s	23.7 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Four-pole
Cable cross-section (phase side)	120 mm²
Cable cross-section (earth side)	120 mm²
Length of phase cable A	600 mm
Length of phase cable B	600 mm
Length of phase cable C	600 mm
Length of phase cable F	600 mm
Length of earthing cable	1800 mm
Cable cross-section	120 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	33.5 kA
Max. short-circuit current I_k1 s	23.7 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product V27E2GP was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. V291ZZT EKV4u0 150 G V291ZZT

GTIN 4013364163997, Customs tariff No. (EU): 85359000, Gross weight: 9.86 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	150 mm²
Max. short-circuit current I_k0.5 s	42.0 kA
Max. short-circuit current I_k1 s	29.6 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Four-pole
Cable cross-section (phase side)	150 mm²
Cable cross-section (earth side)	150 mm²
Length of phase cable A	600 mm
Length of phase cable B	600 mm
Length of phase cable C	600 mm
Length of phase cable F	600 mm
Length of earthing cable	1800 mm
Cable cross-section	150 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	42.0 kA
Max. short-circuit current I_k1 s	29.6 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product V291ZZT was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VQ7PF5A EKV5+0 16 G VQ7PF5A

GTIN 4013364164154, Customs tariff No. (EU): 85359000, Gross weight: 1.98 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	16 mm²
Max. short-circuit current I_k0.5 s	4.5 kA
Max. short-circuit current I_k1 s	3.2 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Five-pole
Cable cross-section (phase side)	16 mm²
Cable cross-section (earth side)	16 mm²
Length of phase cable A	600 mm
Length of phase cable B	600 mm
Length of phase cable C	600 mm
Length of phase cable F	600 mm
Length of phase cable G	600 mm
Length of earthing cable	1800 mm
Cable cross-section	16 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	4.5 kA
Max. short-circuit current I_k1 s	3.2 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VQ7PF5A was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VZKQZB5 EKV5+0 25 G VZKQZB5

GTIN 4013364164161, Customs tariff No. (EU): 85359000, Gross weight: 2.40 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	25 mm²
Max. short-circuit current I_k0.5 s	7.0 kA
Max. short-circuit current I_k1 s	4.9 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Five-pole
Cable cross-section (phase side)	25 mm²
Cable cross-section (earth side)	25 mm²
Length of phase cable A	600 mm
Length of phase cable B	600 mm
Length of phase cable C	600 mm
Length of phase cable F	600 mm
Length of phase cable G	600 mm
Length of earthing cable	1800 mm
Cable cross-section	25 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	7.0 kA
Max. short-circuit current I_k1 s	4.9 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VZKQZB5 was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. V76D5TH EKV5+0 35 G V76D5TH

GTIN 4013364164178, Customs tariff No. (EU): 85359000, Gross weight: 10.00 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	35 mm²
Max. short-circuit current I_k0.5 s	10.0 kA
Max. short-circuit current I_k1 s	6.9 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Five-pole
Cable cross-section (phase side)	35 mm²
Cable cross-section (earth side)	35 mm²
Length of phase cable A	600 mm
Length of phase cable B	600 mm
Length of phase cable C	600 mm
Length of phase cable F	600 mm
Length of phase cable G	600 mm
Length of earthing cable	1800 mm
Cable cross-section	35 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	10.0 kA
Max. short-circuit current I_k1 s	6.9 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product V76D5TH was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. V6VE249 EKV5+0 50 G V6VE249

GTIN 4013364164185, Customs tariff No. (EU): 85359000, Gross weight: 10.00 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	50 mm²
Max. short-circuit current I_k0.5 s	14.0 kA
Max. short-circuit current I_k1 s	9.9 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Five-pole
Cable cross-section (phase side)	50 mm²
Cable cross-section (earth side)	50 mm²
Length of phase cable A	600 mm
Length of phase cable B	600 mm
Length of phase cable C	600 mm
Length of phase cable F	600 mm
Length of phase cable G	600 mm
Length of earthing cable	1800 mm
Cable cross-section	50 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	14.0 kA
Max. short-circuit current I_k1 s	9.9 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product V6VE249 was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VDXTBGF EKV5+0 70 G VDXTBGF

GTIN 4013364164192, Customs tariff No. (EU): 85359000, Gross weight: 10.00 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	70 mm²
Max. short-circuit current I_k0.5 s	19.5 kA
Max. short-circuit current I_k1 s	13.8 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Five-pole
Cable cross-section (phase side)	70 mm²
Cable cross-section (earth side)	70 mm²
Length of phase cable A	600 mm
Length of phase cable B	600 mm
Length of phase cable C	600 mm
Length of phase cable F	600 mm
Length of phase cable G	600 mm
Length of earthing cable	1800 mm
Cable cross-section	70 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	19.5 kA
Max. short-circuit current I_k1 s	13.8 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VDXTBGF was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VGCMAA5 EKV5+0 95 G VGCMAA5

GTIN 4013364162518, Customs tariff No. (EU): 85359000, Gross weight: 10.00 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	95 mm²
Max. short-circuit current I_k0.5 s	26.5 kA
Max. short-circuit current I_k1 s	18.7 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Five-pole
Cable cross-section (phase side)	95 mm²
Cable cross-section (earth side)	95 mm²
Length of phase cable A	600 mm
Length of phase cable B	600 mm
Length of phase cable C	600 mm
Length of phase cable F	600 mm
Length of phase cable G	600 mm
Length of earthing cable	1800 mm
Cable cross-section	95 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	26.5 kA
Max. short-circuit current I_k1 s	18.7 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VGCMAA5 was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VVL7AKP EKV5+0 120 G VVL7AKP

GTIN 4013364164130, Customs tariff No. (EU): 85359000, Gross weight: 10.00 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	120 mm²
Max. short-circuit current I_k0.5 s	33.5 kA
Max. short-circuit current I_k1 s	23.7 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Five-pole
Cable cross-section (phase side)	120 mm²
Cable cross-section (earth side)	120 mm²
Length of phase cable A	600 mm
Length of phase cable B	600 mm
Length of phase cable C	600 mm
Length of phase cable F	600 mm
Length of phase cable G	600 mm
Length of earthing cable	1800 mm
Cable cross-section	120 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	33.5 kA
Max. short-circuit current I_k1 s	23.7 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VVL7AKP was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Part No. VHV1NKR EKV5+0 150 G VHV1NKR

GTIN 4013364164147, Customs tariff No. (EU): 85359000, Gross weight: 10.00 kg, PU: 1.00 pc(s)

Images

Open PDF

Additional information

Technical data

Cable cross-section	150 mm²
Max. short-circuit current I_k0.5 s	42.0 kA
Max. short-circuit current I_k1 s	29.6 kA
Crimped cable lug	PK1
Attention: Please state the relevant Variant No. when ordering.

Version	Five-pole
Cable cross-section (phase side)	150 mm²
Cable cross-section (earth side)	150 mm²
Length of phase cable A	600 mm
Length of phase cable B	600 mm
Length of phase cable C	600 mm
Length of phase cable F	600 mm
Length of phase cable G	600 mm
Length of earthing cable	1800 mm
Cable cross-section	150 mm²
Fully insulated	No
Max. short-circuit current I_k0.5 s	42.0 kA
Max. short-circuit current I_k1 s	29.6 kA
Crimped cable lug	PK1
Standard	EN/IEC 61138 (DIN VDE 0283-3) and EN/IEC 61230 (DIN VDE 0683-100)
Temperature range	–25 °C ... +55 °C
Material (cable)	E-Cu, extra finely stranded and highly flexible
Material (sheath)	Thermoplastic polymer (flexible PVC compound YM2)
Hole (cable lug)	Ø12.5 mm
Attention: Please state the relevant Variant No. when ordering.

Product VHV1NKR was added to Notepad.

Go to Notepad

??store.webshop.add.feedback_de??

??store.webshop.goTo_de??

Earthing and Short-Circuiting Cables, unequipped

Details

Earthing Cable Cu in accordance with IEC 61138

Part No. 716001 ES YM2 16

Product 716001 was added to Notepad.

??store.webshop.add.feedback_de??

Part No. 725001 ES YM2 25

Product 725001 was added to Notepad.

??store.webshop.add.feedback_de??

Part No. 735001 ES YM2 35

Product 735001 was added to Notepad.

??store.webshop.add.feedback_de??

Part No. 750001 ES YM2 50

Product 750001 was added to Notepad.

??store.webshop.add.feedback_de??

Part No. 770001 ES YM2 70

Product 770001 was added to Notepad.

??store.webshop.add.feedback_de??

Part No. 795001 ES YM2 95

Product 795001 was added to Notepad.

??store.webshop.add.feedback_de??

Part No. 712001 ES YM2 120

Product 712001 was added to Notepad.

??store.webshop.add.feedback_de??

Part No. 715001 ES YM2 150

Product 715001 was added to Notepad.

??store.webshop.add.feedback_de??

Single-pole Earthing and Short-circuiting Cables, aluminium version

Part No. VGHVBP5 EKV1+0 35 VGHVBP5

Product VGHVBP5 was added to Notepad.

??store.webshop.add.feedback_de??

Part No. VKVBG8W EKV1+0 50 VKVBG8W

Product VKVBG8W was added to Notepad.

??store.webshop.add.feedback_de??

Single-pole Earthing and Short-Circuiting Cables, copper version

Part No. V4YPRGE EKV1+0 16 V4YPRGE

Product V4YPRGE was added to Notepad.

??store.webshop.add.feedback_de??

Part No. VSY71K4 EKV1+0 25 VSY71K4

Product VSY71K4 was added to Notepad.

??store.webshop.add.feedback_de??

Part No. V9JF26K EKV1+0 35 V9JF26K

Product V9JF26K was added to Notepad.

??store.webshop.add.feedback_de??

Part No. VRJG23Y EKV1+0 50 VRJG23Y

Product VRJG23Y was added to Notepad.

??store.webshop.add.feedback_de??

Part No. VPZBBSL EKV1+0 70 VPZBBSL

Product VPZBBSL was added to Notepad.

??store.webshop.add.feedback_de??

Part No. VZC3FST EKV1+0 95 VZC3FST

Product VZC3FST was added to Notepad.

??store.webshop.add.feedback_de??

Part No. V797FE6 EKV1+0 120 V797FE6

Product V797FE6 was added to Notepad.

??store.webshop.add.feedback_de??

Part No. VB53TC9 EKV1+0 150 VB53TC9

Product VB53TC9 was added to Notepad.

??store.webshop.add.feedback_de??

Two-pole Earthing and Short-Circuiting Cables, copper version

Part No. V7265NS EKV2+0 16 G V7265NS

Product V7265NS was added to Notepad.

??store.webshop.add.feedback_de??

Part No. VZL6TGH EKV2+0 25 G VZL6TGH

Product VZL6TGH was added to Notepad.

??store.webshop.add.feedback_de??

Part No. VPHPZV2 EKV2+0 35 G VPHPZV2

Product VPHPZV2 was added to Notepad.

??store.webshop.add.feedback_de??

Part No. VJ13VWW EKV2+0 50 G VJ13VWW

Product VJ13VWW was added to Notepad.

??store.webshop.add.feedback_de??

Part No. VTJKEZU EKV2+0 70 G VTJKEZU

Product VTJKEZU was added to Notepad.

??store.webshop.add.feedback_de??

Part No. VAM7M6H EKV2+0 95 G VAM7M6H

Product VAM7M6H was added to Notepad.

??store.webshop.add.feedback_de??

Part No. VFV1Z7K EKV2+0 120 G VFV1Z7K

Product VFV1Z7K was added to Notepad.
