BLITZDUCTORconnect – Compact

Universal lightning current and surge arrester

For protecting data bus interfaces as well as measuring and control circuits
High discharge capacity of 3 kA (10/350 µs), 10 kA (8/20 µs)
Max. impulse current carrying capability (8/20 µs) I_max up to 20 kA
Low voltage protection level, also capable of protecting terminal equipment

Compact arrester

Fast and simple cable connection thanks to push-in connection technology
High system availability thanks to fail-safe performance

Function-optimised design with a width of 6 mm

LifeCheck and visual status indication integrated in the module
Simple remote signalling of the status with the help of an optional remote signalling unit
Vibration and shock-tested for safe operation

Details

**Quickly tested – at a glance**
Integrated indication for easy and fast maintenance

lorem ipsum — **Quickly tested – at a glance**
Integrated indication for easy and fast maintenance

**Maximum system availability**
Approvals for use in intrinsically safe measuring circuits

**Connect = Protect**
Push-in connection technology for simple and fast cable connection

**Easy maintenance**
Simple status message with monitoring unit for arrester groups

BCO CL2 B 180

Space-saving, compact lightning current arrester with a width of 6 mm and push-in connection technology with status indication for protecting two single lines for lightning equipotential bonding as well as indirect earthing of shielded cables.
